Τεχνικά Χαρακτηριστικά
| Mounting method | Surface mounted |
|---|---|
| number of rows | 1 |
| Width in number of modular spacings | 6 |
| Type of covering | Cover |
| Cover model | With notch |
| Transparent cover/door | No |
| Signal passing door | Yes |
| With lock | No |
| Type of closure | Other |
| Housing material | Plastic |
| Built-in depth | 64 mm |
| Built-in height | 136 mm |
| Built-in width | 126 mm |
| Inner depth | 48 mm |
| Earthing terminal block | Yes |
| Neutral terminal block | No |
| DIN-rail | No |
|---|---|
| With mounting plate | No |
| Extension possible | No |
| Colour | White |
| EMC-version | No |
| RAL-number | 9010 |
| Degree of protection (IP) | IP30 |
| Height | 140 mm |
| Width | 130 mm |
| Depth | 68 mm |
| Enclosure capacity (Nb of modules) | 6 |
| degree of impact strength (IK) | IK05 |
| Operating / setting temperature (Min-Max) | -10-40 °C |
| Storage temperature (Min-Max) | -20-70 °C |
| Fitted with rainproof plate protection | No |
